System Power Supply 59
4.3.13HP_SystemPhysicalPowerSupply
HP_SystemPhysicalPowerSupply is used to represent an association between HP_PowerSupplyModule
and the computer system that contains this power supply.
Table 4-14
Class: HP_SystemPhysicalPowerSupply
Property name Property implementation
GroupComponent References HP_ComputerSystemChassis
PartComponent References HP_PowerSupplyModule
4.3.14HP_PowerMeter
HP_PowerMeter is used to model the power consumption within power supplies on Integrity Servers.
The Windows specific implementation class is HP_WinPowerMeter. Not all systems support reporting
power consumption information. Note: Power supply numbers for existing instances do not change
when other power supplies are added and removed.
Table 4-15
Class: HP_PowerMeter
Property name Property implementation
CIM_ManagedElement
Caption Power Meter n, where n represents the number of the
power meter instance.
Description Power Meter n provides power monitoring for Power
Suply m, where n represents the number of the power
meter instance and m represents the power supply
instance.
ElementName Power Meter n, where n represents the number of the
power meter instance.
CIM_ManagedSystemElement
OperationalStatus[0] 2 (OK) – if power consumption reported by the sensor
is within normal operating range
P
ower consumption reported by the sensor
is within normal operating range – if
temperature reported by the sensor is within normal
operating range.
StatusDescriptions[0]
HealthState 5 (OK) – if power supply is operating properly
Name Power Supply n, where n is the physical bay number.
CIM_LogicalDevice
CreationClassName HP_ WinPowermeter
DeviceID Unique identifier for this power meter instance.
