SAS HBA 339
Table 17-17 Class: HPSAS_SCSIProtocolEndpoint (CIM_SCSIProtocolEndpoint)
Property name Property implementation
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault 2 (Enabled)
RequestedState 12 (Not Applicable)
CIM_ServiceAccessPoint
CreationClassName HPSAS_SCSIProtocolEndpoint
Name HBA Serial Number
SystemCreationClassName HPSAS_ArraySystem
SystemName HPSAS_ArraySystem.Name
CIM_ProtocolEndpoint
ProtocolIFType 0 (Unknown)
CIM_SCSIProtocolEndpoint
ConnectionType 1 (Other)
OtherConnectionType PCI
Role 4 (Both Initiator and Target)
HPSAS_SCSIProtocolEndpoint
17.3.17HPSAS_SCSIProtocolController
HPSAS_SCSIProtocolController represents a view a SCSI resources on the controller.
Table 17-18 Class: HPSAS_SCSIProtocolController (CIM_SCSIProtocolController)
Property name Property implementation
CIM_ManagedElement
ElementName Controller name and location
For example, HP 8 INT Port SAS/SATA HBA in Slot 3
CIM_ManagedSystemElement
OperationalStatus[0] Operational status of the controller
• 0 (Unknown)
• 2 (OK)
• 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault 2 (Enabled)
