17SAS HBA
17.1Overview
The HP SAS HBA Profile describes host based SAS HBA providers.
The following table details the profiles implemented and files installed by this provider.
Table 17-1 Overview
• HP SAS HBA
Implemented Profiles
• HPWMISAS.dll
Provider Installation Files
• HPWMISASEventMsg.dll
• Cpqmdisk.dll
• Cpqmscsi.dll
• Cpqmsas.dll
• Cpqstmsg.dll
• Cpqstmsg.dll
• Cpqstrutl.dll
• HPWMISRV.exe
• Hpwmistor.exe
• HPWMISAS.mof
• HPWMISASEvent.mof
• HPWMISASRegistration.mof
• HPWMISASErrorMetaData.mof
17.2Use cases
For specific use cases, see HP SAS HBA Profile (P00122).
This provider implements a read only version of the profiles referenced. No configuration functionality
is supported by this provider. This is in accordance with the SNIA profiles since HP does not advertise
and ConfigurationService type classes.
17.3Class implementations
The following sections define the supported properties for the SAS HBA provider. For details of each
property, see the HP SAS HBA profile (P00122) and associated MOF file.
17.3.1HPSAS_ArraySystem
HPSAS_ArraySystem represents the top level system. There is one instance per HBA.
