Smart Array 194
Table 15-4 Class: HPSA_StorageVolume (CIM_StorageVolume)
Property name Property implementation
Identify() See HP Smart Array Profile
PhysicalDrvMultipathAccess This is a new property added to the definition of
HPSA_StorageVolume. The definition is:
Uint16 PhysicalDrvMultipathAccess –
Value – Valuemap
• 1 (not supported) – Not supported by Array
Firmware
• 2 (not configured) – Supported by Array Firmware
but not configured
• 3 (configured redundant) – Volume is configured
with redundant physical paths on all physical
drives that make up the volume.
• 4 (configured non-redundant) – Volume is
configured with redundant paths but is currently
not redundant possibly due to failure of 1 or more
paths or a configuration error.
Primordial False – Can create and delete this element.
15.3.4HPSA_DiskDrive
HPSA_DiskDrive represents the Hard drives connected to Smart Array controllers.
Table 15-5 Class: HPSA_DiskDrive (CIM_DiskDrive)
Property name Property implementation
CIM_ManagedElement
ElementName Disk location
Examples:
Port: 1E Box 1 Bay: 5)
Port: 1E,2E Box 1, Bay:5 (SAS Disk with dual port)
CIM_ManagedSystemElement
Name Drive Serial Number
OperationalStatus[0] Operational Status for the disk drive
• 0 (Unknown)
• 2 (OK)
• 5 (Predictive Failure)
• 6 (Error) In the multipath scenario, if one or more
path to volume fails, OperationalStatus is
Degraded. If all path to volume fails,
OperationalStatus is Error.
OperationalStatus[1] See Smart Array Profile
CIM_LogicalElement
