Smart Array 238
15.3.97HPSA_ DiskDriveTSASSCSIProtocolEndpoint
(Association)
Table 15-98 Class: HPSA_DiskDriveTSASSCSIProtocolEndpoint (CIM_SAPAvailableForElement)
Property name Property implementation
AvailableSAP Points to reference of HPSA_TSASSCSIProtocolEndpoint
ManagedElement Points to reference of HPSA_DiskDrive
15.3.98HPSA_SCSIInitiatorTargetLogicalUnitPath
The following class instance is created only with SAS controllers supporting multipath supported
firmware and configured in dual domain mode.
Table 15-99
Class: HPSA_SCSIInitiatorTargetLogicalUnitPath (CIM_ SCSIInitiatorTargetLogicalUnitPath)
Property name Property implementation
Initiator Reference to aninstance of
HPSA_ISASSCSIProtocolEndpoint
Target Reference to an instance of
HPSA_TSASSCSIProtocolEndpoint
LogicalUnit Reference to an instance of HPSA_StorageExtent
• 0 (unknown) if the path status cannot be
ascertained
State
• 2 (active) if the path is active and healthy
• 5 (Path Error) path has an error condition
• 3 (passive) path is healthy but is not active or is
the standby path
15.4Supported indications
15.4.1Physical Drive Status Changed to OK
Table 15-100 HPSA_DeviceIndication: Physical Drive status changed to OK
Property name Property implementation
CIM_Indication
IndicationIdentifier GUID string generated at the time of indication
PerceivedSeverity 2 (Informational)
IndicationTime Time of indication
CIM_AlertIndication
