CPU 33
Table 3-2 Class: HP_Processor Properties
Property name Property implementation
• 2 (Enabled)
EnabledState
• 3 (Disabled)
RequestedState 12 (Not Applicable)
EnabledDefault 2 (Enabled)
CIM_LogicalDevice
SystemCreationClassName HP_WinComputerSystem
SystemName Computer system name from Windows API
GetComputerSystemName()
CreationClassName HP_Processor
DeviceID
• Cabinet x Cell y Socket z (for cellular
systems)
• Socket z (for non-cellular systems)
CIM_Processor
• 1 (CPU Enabled)
CPUStatus
• 2 (CPU Disabled by User using BIOS Setup)
• 3 (CPU Disabled By BIOS (POST Error))
• 7 (Other)
Family Processor family number from SMBIOS (for example,
179 for Intel(R) Xeon(TM) and 130 for Itanium (TM)
processor)
MaxClockSpeed Maximum clock speed in MHz (for example, 3600)
CurrentClockSpeed Current clock speed in MHz (for example, 3066)
DataWidth 64 x64/ia64 processors
AddressWidth 64 x64/ia64 processors
ExternalBusClockSpeed External bus clock speed in MHz (for example, 533)
Characteristics Characteristics[0]: 2 (64-bit Capable)
NumberOfEnabledCores Number of enabled and operational cores for this
processor (for example, 1, 2, 4)
HP_Processor
3.3.2HP_ProcessorCapabilities
HP_ProcessorCapabilities extends the class CIM_ProcessorCapabilities to model the processor
capabilities.
The following properties are implemented.
