System fan 69
Table 5-9 Class: HP_SystemFan
Property name Property implementation
PartComponent References HP_Fan
5.3.9HP_FanModule
HP_FanModule is used to model the physical fans on Integrity Servers. The Windows specific
implementation class is HP_FanModule. Note: Fan numbers for existing instances do not change
when other fans are added and removed.
Table 5-10
Class: HP_FanModule
Property name Property implementation
CIM_ManagedElement
Caption
Fan n:Location, where n represents the number of
the fan instance. For example, Fan 1:cabinet 0 –
blower 0.
Description
Fan n:Location provides cooling for FanType.
StatusDescription, where n represents the number of the
fan instance, FanType represents the corresponding
string value of the FanType enumeration and
StatusDescription represents the value of
StatusDescriptions[0]
ElementName
Fan n:Location, where n represents the number of
the fan instance. For example, Fan 1:cabinet 0 –
blower 0.
CIM_ManagedSystemElement
• 2 (OK) – if fan is operating properly;
OperationalStatus[0]
• 6 (Error) – if fan has failed
StatusDescription[0]
• Fan is operating properly – if
OperationalStatus[0] is 2 (OK)
• Fan has failed – if OperationalStatus is 6
(Error)
• 5 (OK) – if fan is operating properly
HealthState
• 20 (Major Failure) – if fan has failed
Name
Fan n, where n represents the number of the fan
instance.
CIM_ PhysicalElement
CreationClassName HP_FanModule
Tag Unique identifier for this fan module instance.
CIM_ PhysicalPackage
