SAS HBA 330
Table 17-5 Class: HPSAS_DiskDrive (CIM_DiskDrive)
Property name Property implementation
NegotiatedSpeed 0
17.3.5HPSAS_StorageExtent
HPSAS_StorageExtent represents the consumable storage that is available on a disk drive. There is
one instance per disk drive.
Table 17-6 Class: HPSAS_StorageExtent (CIM_StorageExtent)
Property name Property implementation
CIM_ManagedElement
ElementName Disk location
For example, Bay: 5
CIM_ManagedSystemElement
Name Serial number of drive
OperationalStatus[0] Operational Status for the disk drive
• 0 (Unknown)
• 2 (OK)
• 5 (Predictive Failure)
• 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault 2 (Enabled)
EnabledState 5 (Not Applicable)
RequestedState 12 (Not Applicable)
CIM_LogicalDevice
CreationClassName HPSAS_StorageExtent
DeviceID Opaque ID
SystemCreationClassName HPSAS_ArraySystem
SystemName HPSAS_ArraySystem.Name
CIM_StorageExtent
BlockSize Block size in bytes
ConsumableBlocks Total number of blocks on disk drive
ExtentStatus[0] Indicates extended status for the disk drive
• 2 (None)
• 11 (Rebuild – disk drive is currently rebuilding
data)
