Smart Array 218
15.3.31HPSA_StorageCapabilities
HPSA_StorageCapabilities represents the possible capabilities of a Storage Pool.
Table 15-32 Class: HPSA_StorageCapabilities (CIM_StorageCapabilities)
Property name Property implementation
CIM_ManagedElement
ElementName For Primodial Pools: Controller name and location
Examples:
• Smart Array in Slot 3, for internal
• Active Controller: MSA500 in SystemCab03, for
external
For Concrete Pools: Controller name and
location:Array identifier
Examples:
• Smart Array in Slot 3: Array – 0, for internal
• Active Controller: MSA500 in SystemCab03:
Array – 1, for external
CIM_Capabilities
InstanceID Key: Opaque key
CIM_StorageCapabilities
• 1—When number of drives is an odd number
DataRedundancyDefault
• 2—When number of drives is an even number
(For example, pool can be configured for
mirroring.)
• 0—When there is no drives connected
• 1—When number of drives is an odd number
DataRedundancyMax
• 2—When number of drives is an even number
(For example, Pool can be configured for
mirroring.)
• 0—When there is no drives connected
DataRedundancyMin 1
DeltaReservationDefault 0
DeltaReservationMax 0
DeltaReservationMin 0
ElementType 5 (Storage Pool)
• True—When number of drives > 1 (For example,
pool can be configured for redundancy.)
NoSinglePointOfFailure
• False—When number of drives <= 1
• True—When number of drives > 1 (For example,
pool can be configured for redundancy.)
NoSinglePointOfFailureDefault
• False—When number of drives <= 1
