Smart Array 221
Table 15-35 Class: HPSA_TSASSCSIProtocolEndpoint
Property name Property implementation
Name
HPSA_DiskDrive.DeviceID:unique value,
where HPSA_DiskDrive.DeviceID is the DeviceID
property of the instance of HPSA_DiskDrive associated
to this instance via the association
HPSA_DiskDriveTSASSCSIPE, and unique value is
a unique value across all instances of
HPSA_TSASSCSIProtocolEndpoint. For example, a
dual port disk has two instances of
HPSA_TSASSCSIProtocolEndpoint with the name
properties set to:
• PH77MW3991:0:0
• PH77MW3991:0:1
CIM_ServiceAccessPoint
HPSA_ArraySystem
SystemnCreationClassName
SystemName The property value of HP_ArraySystem.name
HPSA_TSASSCSIProtocolEndpoint
CreationClassName
CIM_EnabledLogicalElement
EnabledDefault 2 (Enabled)
RequestedState 12 (Not Applicable)
HPSA_SCSIProtocolEndpoint
ProtocolIFType 1 (Other)
SCSI
OtherTypeDescription
Role 3 (Target)
HPSA_TSASSCSIProtocolEndpoint
Path Redundancy path status
• 0 (Unknown)
• 2 (Active)
• 3 (Passiver)
• 5 (Path Error)
15.3.35HPSA_ISASSCSIProtocolEndpoint
HPSA_ISASSCSIProtocolEndpoint represents each port on the smart array controller. This class is
generated only if the SAS controller has multipath supported firmware.
Table 15-36
Class: HPSA_ISASSCSIProtocolEndpoint
Property name Property implementation
CIM_ManagedElement
