Smart Array 220
Table 15-34 Class: HPSA_StorageEnclosureLocation (HP_Location)
Property name Property implementation
Caption Enclosure location
Port m Box n, where m is the port and n is the box
number. For dual port SAS disks, all port numbers are
displayed.
Description Enclosure location
Port m Box n, where m is the port and n is the box
number. For dual port SAS disks, all port numbers are
displayed.
Name Key
PhysicalPosition Key
• Unknown for Undetermined
ElementLocationTag
• External for external enclosures
• Internal for drive cages located within the host
chassis
ElementLocationTagDesc 19 (Box)
15.3.34HPSA_TSASSCSIProtocolEndpoint
HPSA_TSASSCSIProtocolEndPoint represents each port on SAS Drive. This class is generated only if
the SAS controller connected to the disk has multipath supported firmware.
Table 15-35
Class: HPSA_TSASSCSIProtocolEndpoint
Property name Property implementation
CIM_SCSIProtocolEndpoint
CIM_ManagedElement
ElementName
Protocol Endpoint for xxx, where xxx is the
value populated in the caption property of the instance
of HPSA_TSASPort associated to this instance via the
association HPSA_TSASPortTSASSCSIPE.
Caption
Protocol Endpoint for xxx, where xxx is the
value populated in the caption property of the instance
of HPSA_TSASPort associated to this instance via the
association HPSA_TSASPortTSASSCSIPE.
CIM_ManagedSystemElement
