Host Discovered Resources (HDR) 506
Table 22-4 Class: HPHDR_SCSIProtocolEndPointTarget
Property name Property implementation
CIM_ManagedElement
Caption Path Name of Target
For example, SCSITarget 1:2:3, where 1 is the initiator
ID, 2 is the path ID, and 3 is the target ID
ElementName Name of the OS Volume associated to this Initiator
Path combination
For example, \\?\Volume{a0acd7e0-442d-11dc-
8bd2-806d6172696f}\
CIM_EnabledLogicalElement
EnabledDefault 2 (Enabled)
RequestedState 12 (Not Applicable)
CIM_ManagedSystemElement
Name
The SCSI ID in the form SCSI Initiator portid:
pathid:Targetid
For example, SCSITarget 1:2:3, where 1 is the initiator
ID, 2 is the path ID, and 3 is the target ID.
CIM_ServiceAccessPoint
CreationClassName HPHDR_SCSIProtocolEndpointTarget
SystemCreationClassName HPHDR_ComputerSystem
SystemName Name of the host. For example,
aa.bb.abccorp.net.
CIM_SCSIProtocolEndpoint
ConnectionType 1 (Other)
Roll 3 (Target)
CIM_ProtocolIFType
ProtocolIFType 0 (Unknown)
22.3.4HPHDR_LogicalDisk
HPHDR_LogicalDisk represents the Logical Disks in the system. There is one instance per Logical Disk
Drive.
Table 22-5
Class: HPHDR_LogicalDisk
Property name Property implementation
CIM_StorageExtent
• The block size in bytes.
BlockSize
• 1
