SCSI HBA 410
Table 18-19 Class: HPSCSI_DASCSIProtocolEndpoint (CIM_SCSIProtocolEndpoint)
Property name Property implementation
ProtocolIFType 0 (Unknown)
CIM_SCSIProtocolEndpoint
ConnectionType 3 (Parallel SCSI)
Role 2 (Initiator)
18.3.19HPSCSI_HBASCSIProtocolController
HPSCSI_HBASCSIProtocolController represents a view of SCSI resources on the SCSI HBA. This is
required to model the presentation of SCSI luns to the host system.
Table 18-20 Class: HPSCSI_HBASCSIProtocolController (CIM_SCSIProtocolController)
Property name Property implementation
CIM_ManagedElement
ElementName Controller name and location (for example, SCSI
Controller Port 1 in Slot 4)
CIM_ManagedSystemElement
OperationalStatus[0] Operational status of the controller
• 0 (Unknown)
• 2 (OK)
• 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault 2 (Enabled)
EnabledState 5 (Not Applicable)
RequestedState 12 (Not Applicable)
CIM_LogicalDevice
CreationClassName HPSCSI_HBASCSIProtocolController
DeviceID Opaque key
SystemCreationClassName HPSCSI_HBAComputerSystem
SystemName HBA index
CIM_ProtocolController
MaxUnitsControlled 15
CIM_SCSIProtocolController
