FC HBA 304
Table 16-3 Class: HPFCHBA_FCPort
Property name Property implementation
• other
OtherPortType
• Not present
• Fabric
• Public Loop
• FL Port
• Fabric Port
• Fabric expansion port
• Generic Fabric Port
• Private Loop
• Point to Point
PortType 1 (Other)
Speed One of the following (in Bits per Second):
• 0
• 1000000000
• 2000000000
• 10000000000
UsageRestriction 4 (not restricted)
CIM_NetworkPort
LinkTechnology 4 (FC)
PermanentAddress PortWWN
PortNumber Port number
SupportedMaximumTransmissionUnit Port maximum frame size
CIM_FCPort
ActiveFC4Types[] Array of port active FC4 type bits
SupportedFC4Types[] Array of port supported FC4 type bits
16.3.3HPFCHBA_PortController
HPFCHBA_PortController is a logical device corresponding to a hardware network port controller.
Table 16-4 Class: HPFCHBA_PortController
Property name Property implementation
CIM_ManagedElement
ElementName Product Name
CIM_ManagedSystemElement
Name PortWWN
CIM_LogicalElement
