Smart Array 217
Table 15-31 Class: HPSA_ArrayControllerLocation (HP_Location)
Property name Property implementation
Caption Controller name and location
Examples:
• Smart Array in Slot 3, for internal
• Active Controller: MSA500 in SystemCab03, for
external
Description Controller name and location
Examples:
• Smart Array in Slot 3, for internal
• Active Controller: MSA500 in SystemCab03, for
external
ElementName Controller name and location
Examples:
• Smart Array in Slot 3, for internal
• Active Controller: MSA500 in SystemCab03, for
external
CIM_Location
Name Opaque key
PhysicalPosition Opaque key
HP_Location
ElementLocationTag for Internal HBAs: PCI Slot Number
Examples:
• 3 – for adapter in PCI Slot 3
• 0 – for Embedded adapter
For external controllers: Controller number per chassis
label
Examples:
• Controller 1
• Controller 2
• 23 (Adapter)—for Internal HBAs
ElementLocationTagDesc
• 1 (Hood Tag)—for External Controllers
LocationInformation[0] For internal HBAs: PCI Slot number
Examples:
• 3 – PCI Slot 3
• 0 – Embedded on Motherboard
Not required for External Storage Systems
• 3 (PCI Slot) – for internal HBAs
LocationInfoDesc[0]
• Not required for External Storage Systems
HP_ArrayControllerLocation
