HP StorageWorks D2D - Backup Systems User Manual

Figure 8 Insert the HP D2D server into the rack
NOTE:
The rear ends of the rails have a CTO bracket that must overlap the chassis tab in order to secure
the HP D2D to the rails.
Figure 9 CTO bracket location
4. Secure the HP D2D to the rack rails using thumbscrews on the front bezel.
Connecting and installing the HP D2D Backup System34
