Firmware fault (OK)Alternately flashingAlternately flashingAlternately flashing
Connected at 1 Gb/s
nl
Activity at 1 Gb/s (OK)
On
nl
Flashing
OffOff
Connected at 2 Gb/s
nl
Activity at 2 Gb/s (OK)
Off
On
nl
Flashing
Off
Connected at 4 Gb/s
nl
Activity at 4 Gb/s (OK)
OffOff
On
nl
Flashing
Beacon mode
The HP D2D Backup System supports a Beacon LED sequence, which helps a user identify which unit
is being configured, if several are connected to the network. There is also a Beacon LED on the
individual disks so that you can identify a specific disk within the HP D2D.
Use the Network page of the Web Management Interface to turn Beacon Mode on and off for the
HP D2D Backup System. This turns the Beacon LED on the front and the rear of the HP D2D solid blue.
If you do not switch off Beacon Mode, it will continue for 5 minutes. See also
“Network (Configuration)” on page 120. You can also switch Beacon mode on and off by pressing
the LED on the front panel.
Use the Storage-RAID page of the Web Management Interface to turn Beacon Mode on and off for
a specific disk. This turns the Beacon LED on the disk solid blue.
LEDs74
