2. Tighten the two captive screws to secure the PCI cage to the chassis.
Figure 21 Securing the PCI cage
Replacing the top cover
• Reconnect the network cable(s) and the power cord(s).
NOTE:
If you are using the FC interface, reconnect all cables connecting the FC card to the Fibre
Channel switch.
Connecting an external or rackmount storage device
NOTE:
You can only connect an external or rackmount storage device, if you have already installed a
recommended HBA.
Connect the external or rackmount storage device, as described in the documentation accompanying
the storage device. Refer to the “User Guide” that is supplied with the storage device for more detailed
information about device usage and LED troubleshooting.
NOTE:
If you are connecting to a 1U or 3U rackmount enclosure for internal storage devices, the appropriate
cables for the rackmount shelf must be used. Please refer to the rack documentation for further details.
D2D Backup System HP D2D4112 51
