HPE FlexNetwork 5510 HI Series

312
[SwitchD-bgp-default-ipv4] peer 10.220.2.16 enable
[SwitchD-bgp-default-ipv4] quit
[SwitchD-bgp-default] quit
# Display the IP routing table on Switch D.
[SwitchD] display ip routing-table protocol bgp
Summary count : 3
BGP Routing table Status : <Active>
Summary count : 3
Destination/Mask Proto Pre Cost NextHop Interface
192.168.64.0/24 BGP 255 1 10.220.2.16 Vlan200
192.168.74.0/24 BGP 255 1 10.220.2.16 Vlan200
192.168.99.0/24 BGP 255 1 10.220.2.16 Vlan200
BGP Routing table Status : <Inactive>
Summary count : 0
The output shows that Switch D has learned routes to 192.168.64.0/24, 192.168.74.0/24, and
192.168.99.0/24 through BGP.
# Verify that Switch D can ping hosts on networks 192.168.74.0/24, 192.168.99.0/24, and
192.168.64.0/18. (Details not shown.)
5. Configure route summarization on Switch C to summarize 192.168.64.0/24, 192.168.74.0/24,
and 192.168.99.0/24 into a single route 192.168.64.0/18, and disable advertisement of specific
routes.
[SwitchC-bgp-default-ipv4] aggregate 192.168.64.0 18 detail-suppressed
[SwitchC-bgp-default-ipv4] quit
[SwitchC-bgp-default] quit
Verifying the configuration
# Display IP routing table on Switch C.
[SwitchC] display ip routing-table | include 192.168
192.168.64.0/18 BGP 130 0 127.0.0.1 NULL0
192.168.64.0/24 OSPF 150 1 172.17.100.1 Vlan100
192.168.74.0/24 OSPF 150 1 172.17.100.1 Vlan100
192.168.99.0/24 OSPF 150 1 172.17.100.1 Vlan100
The output shows that Switch C has a summary route 192.168.64.0/18 with the output interface
Null0.
# Display IP routing table on Switch D.
[SwitchD] display ip routing-table protocol bgp
Summary count : 1
BGP Routing table Status : <Active>
Summary count : 1
Destination/Mask Proto Pre Cost NextHop Interface
192.168.64.0/18 BGP 255 0 10.220.2.16 Vlan200
