HTA HT2800T - Page 257

HT2800T_en_c.doc Page 257 of 275
12.1.2.1 Vial specifications
• Vials must be approved for head space techniques;
• Rounded end;
• Clear or amber glass (amber glass is suitable for light sensitive samples).
Specifications for 20ml vials
Figure 213: 20ml sample vial dimensions
10mm
min
79mm
max
77mm min
67mm
max
2mm
min
22.4mm
to
23.0mm
Warning
Correct sample vial dimensions are essential for proper operation. Vials that do not comply
with these guidelines should cause autosampler errors. Service calls and repairs found to
be due to vials and microvials that do not comply with these guidelines are not covered
under
warranty
or
the service contract.
