HTA HT2800T - Sample Vials

HT2800T_en_c.doc Page 263 of 275
Please note that if Bar Code reader Module has been purchased, the syringe length cannot
exceed the one indicated below.
Figure 216: Maximum syringe length with Bar Code Reader Module HT2800T (Liquid mode)
12.2.1.1 How to select correct syringe volume
Look at the following table to check which kind of syringe you need according to the injection
volume.
Injection Volume Range Suggested syringe
0.5-5ul 10ul
0.2-1ul 5l
0.01-0.3ul 0.5l
12.2.2 Sample vials
General specifications:
● Supported caps; screw, snap or crimp caps.
HTA Part Number Description
1.29.961
12x32 (2ml) vials with snap cap
MAX:222mm
