HT2800T_en_c.doc Page 269 of 275

13.1 RS232C interface (optional)

RS232C Connector, DB9 Connector

DB9

pin #

Function

Note

1 N.C.

n.c.

2 TX

Transmission

3 RX

Receiving

4 DSR

Internally connected with DSR signal

5 DGND

6 DTR

Internally connected with DTR signal

7 CTS

8 RTS

9 N.C.
