7.10.1 “Change from Headspace to Liquid mode” At the end of the change mode
procedure, it is always necessary to adjust the injector alignment (see point below).
16. Align the autosampler on the GC Injector(s) (see paragraphs 4.2.1.2 “Alignment:
Front Injector” and Errore. L'origine riferimento non è stata trovata. “Errore. L'origine
riferimento non è stata trovata.”).
17. Modify the needle draw depth inside the sample vial see paragraph 4.2.1.5 “Alignment:
Tray Install”.
18. Finish the installation (see paragraph 3.8 “Final installation operations”).
3.3.1 Autosampler installation on the mounting plate
Please follow these instructions in the following order:
1. Ensure that the autosampler mounting plate is correctly installed on the analyzer and
that it allows the correct centering of the autosampler over the injector. The instructions
for mounting plate installation are not available in this manual (for this information see
the service documentation). The mounting plate is specific for the GC brand and model.
The following figure shows an example:
Warning
Follow the instructions with the autosampler switched off. Moving the unit with the
autosampler switched ON can cause serious damage to the autosampler.
