HT2800T_en_c.doc Page 37 of 275
•
The oven cover can rotate 35°(open/close position);
•
The orbital shaker allows vial(s) agitation with a programmable speed.
•
The fan is used to assist temperature stabilization and the cooling down of the oven.
The movements are made with DC motors, with position control made by encoders.
2.3 Tool kit
The autosampler is provided with a tool kit containing:
1. Syringe pointer that can be used for locking/unlocking the autosampler from the
mounting kit (see paragraphs 3.3.1 “Autosampler installation on the mounting plate” and
3.3.1.1 “Unlock the autosampler from the mounting kit”).
Figure 31: Syringe pointer
2. Allen key (2.5mm) that it is used for syringe replacement (see paragraph 9.1.5 “Syringe
replacement in the syringe warmer assembly (Headspace mode)“:
Warning
Do not try to open or close the sample tray manually, unless it is strictly necessary. In this case,
follow the instructions of paragraph 8.17.1 “Tray opening by hand“).
Warning
If necessary, it is possible to move the turret and needle motors by hand, very carefully, but only
when the autosampler is switched off. Rapid movements or movements with the autosampler
switched on can damage the autosampler.
