12.1.2.2 Vial labeling
• Printer Specification:
• Resolution:
• 600 dpi Thermal Transfer printer (Advised);
• 300 dpi Thermal Transfer printer (Minimum).
• Label Specification:
• Label dimensions:
20ml sample vials 10ml sample vials 6ml sample vials
Advised 36x71mm 26x71mm 20x68mm
Maximum 36x73mm 26x73mm 20x70mm
• Label material:
• Opaque blank adhesive label.
• Printing orientation:
• Print with Bar Code bar perpendicular to printing way.
12.1.2.3 Bar Code Specifications
Code type Maximum characters readable
Code 128 7 alphanumeric characters
Interleaved 2 of 5 7 numeric characters
Code
93
7
numeric characters
UPC-E 7 numeric characters (fixed)
EAN 8 7 numeric characters (fixed)
The code type must be set by HTA Autosampler Manager. It
is advised to:
• Use always code with checksum in order to detect possible reading errors.
• Apply the Bar Code label on the vial, paying attention not to overlap it excessively.
• Position the vial with the Bar Code label oriented toward the Bar Code Reader Module
HT2800T. Avoid to position the vial with any eventual label overlap oriented toward Bar
Code Reader Module.
