Quidway S3000-EI Series Ethernet Switches Chapter 1
ACL Configuration
Huawei Technologies Proprietary
1-10
1.3 ACL Configuration Example
1.3.1 Advanced ACL Configuration Example
I.
company network is
ayment query server
129.110.1.2). It is required to
properly configure the ACL and limit the department other than the Office of President
n 8:00 and 18:00. The Office of President (at
129.111.1.2) can access the server without limitation.
Networking requirements
The interconnection between different departments on a
implemented through the 100M ports of the Ethernet Switch. The p
of the Financial Dept. is accessed via Ethernet1/1 (at
access the payment query server betwee
II. Networking diagram
Administration Department
subnet address
10.120.0.0
Financial Department
Office of President
uery server
0.1.2
129.111.1.2
Pay q
129.11
Switch
#1
#4
#3
#2
subnet address
10.110.0.0
Connected to a router
e
Figure 1-2 Access control configuration exampl
III. Configuration procedure
 Note:
In the following configurations, only the comm
listed.
ands related to ACL configurations are
1) Define the work time range
[Quidway] time-range huawei 8:00 to 18:00 working-day
the payment server.
Enter the named advanced ACL, named as traffic-of-payserver.
[Quidway] acl name traffic-of-payserver advanced match-order config
# Define time range from 8:00 to 18:00.
2) Define the ACL to access
#
