Operation Manual - Port
Quidway S3000-EI Series Ethernet Switches Chapter 2
Link Aggregation Configuration
Huawei Technologies Proprietary
2-3
II. Networking diagram
Link aggregation
Switch B
Switch A Switch C
Figure 2-1 Configure link aggregation
III. Configuration procedure
ease configure Switch B in the
similar way to activate aggregation.
n of the link aggregation.
Master port: Ethernet0/1
Other sub-ports:
Ethernet0/3
Mode: both
g
rompt of configuration failure when configuring link
sting link aggregations. If not, take the next step.
z Check if there are no more than eight ports in one group.
z If correct, configure the link aggregation again.
The following configurations are used for Switch A, pl
# Aggregate Ethernet0/1 through Ethernet0/3.
[Quidway] link-aggregation ethernet0/1 to ethernet0/3 both
# Display the informatio
[Quidway] display link-aggregation ethernet0/1
Ethernet0/2
2.5 Ethernet Link Aggregation Troubleshootin
Fault: You might see the p
aggregation.
Troubleshooting:
z Check the input parameter and see whether the starting number of Ethernet port is
smaller than the end number. If yes, take the next step.
z Check whether the Ethernet ports that are in the configured range belong to any
other exi
z Check whether the ports to be aggregated operate in the same speed and full
duplex mode. If yes, take the next step.
