Huawei Quidway S3000-EI Series User Manual

Operation Manual - Port
Quidway S3000-EI Series Ethernet Switches Chapter 2
Link Aggregation Configuration
Huawei Technologies Proprietary
2-2
Table 2-1 Aggregating Ethernet ports
Operation Command
Aggregate Ethernet ports
link-aggregation port_num1 to port_num2 { bo
th |
ingress }
Remove a configured link
k-aggregation { master_port_num | all }
aggregation
undo lin
Mbps speed, full duplex), or 1000M_FULL (1000Mbps speed,
2.3 Disp
Note that the Ethernet ports to be aggregated can not work in auto-negotiation mode
and must work in the same mode, which can be 10M_FULL (10Mbps speed, full
duplex), 100M_FULL (100
full duplex), otherwise, they cannot be aggregated.
lay and Debug Link Aggregation
After the above configuration, execute display command in any view to display the
running of the link aggregation configuration, and to verify the effect of the
configuration.
Table 2-2 Display the information of the link aggregation
Operation Command
Display the information of
the link aggregation
display link-aggregation [ master_port_num ]
2.4 Link Aggregation Configuration Example
I. Networking requirements
egation commands to aggregate several ports
oming payload balance among all the member ports.
ally used for Trunk ports. Since the Trunk port allows
o pass through, the heavy traffic needs balancing among
is connected to the Ethernet Switch (Switch B) in the
upstream via the aggregation of three ports, Ethernet0/1 through Ethernet0/3.
The following example uses the link aggr
and implement the outgoing/inc
The link aggregation is typic
frames from several VLANs t
all the ports.
Ethernet Switch (Switch A)
