Operation Manual - Integrated Management
Quidway S3000-EI Series Ethernet Switches Chapter 2
HGMP V2 Configuration
Huawei Technologies Proprietary
2-18
, you
cannot configure the member device. The user level will be inherited from the
administrator device when you configure the member device on the administrator
e
the user password of the member device is different from the administrator device
device. For example, system will retain in as user view when you configure the member
device on the administrator device.
Authorization is also required when you exit the member device view on th
administrator device. After passing the authorization, the system will enter user view
automatically.
Perform the following configuration in user view.
Table 2-23 Member accessing
Operation Command
Member accessing
cluster switch-to { member-num |
mac-address H-H-H | administrator }
Note that, when executed on the administrator device, if the parameter member-n
specifying member number is omitted, error message prompts. Enter quit to s
um
top
switchover operation
2.4.13 Display and Debug Cluster
A ay comm o display the
run
T
.\
fter the above configuration, execute displ and in any view t
ning of the Cluster configuration, and to verify the effect of the configuration.
able 2-24 Display and Debug Cluster
Operation Command
Display cluster state and statistics
displa
y cluster
Display the information of Candidate
devices.
display cluster candidates
[ mac-address H-H-H | verbose ]
Display the information about member
display cluster membe
devices.
rs
[ member-num | verbose ]
2.5 HGM
I. Net
Set up a cluster of three switches and configure an administrator device to manage the
P V2 Configuration Example
work requirments
other two members. The administrator device is connected with the members via
Ethernet0/1 and Ethernet0/2 respectively. It is connected to the external network via
