Huawei Quidway S3000-EI Series User Manual

Operation Manual - STP
Quidway S3000-EI Series Ethernet Switches Chapter 1
MSTP Region-configuration
Huawei Technologies Proprietary
1-18
2 * (forward-delay - 1seconds) >= maximum-age
max = 2 * (hello + 1.0 seconds)
dia
cal
By
sec
1.2.8 Config
Th
tra
Th he
Yo
I. Co
Pe
able 1-10 Configure the max transmission speed on a port
imum-age >
You are recommended to use the stp root primary command to specify the network
meter and Hello Time of the switching network, thus MSTP will automatically
culate and give the rather desirable values.
default, Forward Delay is 15 seconds, Hello Time is 2 seconds, and Max Age is 20
onds.
ure the Max Transmission Speed on a Port
e max transmission speed on a port specifies how many MSTP packets will be
nsmitted every Hello Time via the port.
e max transmission speed on a port is limited by the physical state of the port and t
network structure. You can configure it according the network conditions.
u can configure the max transmission speed on a port in the following ways.
nfigure in system view
rform the following configuration in system view.
T
Operation Command
Configure the max transmission speed
on a port.
stp interface inter
packetnum
face-list transit-limit
Restore the max transmission speed on
undo
a port.
stp interface interface-list
transit-limit
II
.
Configure the max transmission speed on a port
. Configure in Ethernet port view
Perform the following configuration in Ethernet port view
Table 1-11
Operation Command
Configure the max transmission speed on a port.
stp tr
ansit-limit packetnum
Restore the max transmission speed on a port.
undo stp transit-limit
You can configure the max transmission speed on a port with either of the
above-mentioned measures. For more about the commands, refer to the
Command
Manual.
