Context
Do as follows on the NQA client (TCP client):
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
nqa test-instance admin-name test-name
An NQA test instance is created and the test instance view is displayed.
Step 3 Run:
test-type tcp
The test type is set to TCP.
Step 4 Run:
destination-address ipv4 ip-address
The destination IP address is configured.
Step 5 To configure the destination port number, run the destination-port port-numbercommand.
Step 6 (Optional) Perform the following as required to configure other parameters for the TCP test ( For
detailed parameter configurations, see the chapter Configuring Universal NQA Test
Parameters ):
l To configure the VPN instance to be tested, run the vpn-instance vpn-instance-name
command.
NOTE
Only S5700EI and S5700HI support the vpn-instance command.
l To configure the source IP address, run the source-address ipv4 ip-address command.
l To configure the source port number, run the source-port port-numbercommand.
l To configure the interval for sending test packets, run the interval seconds interval
command.
l To configure the percentage of the failed NQA tests, run the fail-percent percentcommand.
l To configure the NQA test packets to be sent without searching the routing table, run the
sendpacket passroute command.
Step 7 Run:
start
The NQA test is started.
Select the start mode as required because the start command has several forms.
l To perform the NQA test immediately, run the start now [ end { at [ yyyy/mm/dd ]
hh:mm:ss | delay { seconds second | hh:mm:ss } | lifetime { seconds second | hh:mm:ss } } ]
command.
The test instance is started immediately.
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 6 NQA Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
282
