The destination IP address of the LSP Jitter test is configured.
Step 6 (Optional) Perform the following as required to configure other parameters for the LSP Jitter
test:
l To configure the response mode of the Echo packet, run the lsp-replymode { no-reply |
udp | udp-via-vpls | udp-router-alert | level-control-channel } command.
NOTE
In a uni-directional LSP Ping test, if the lsp-replymode no-reply command is configured, the test
result displays that the test fails regardless of whether the test, actually, is successful or fails. If the test
is successful, the test result also displays the number of the timeout packets. If the test fails, the test
result displays the number of the discarded packets.
l To configure the source IP address, run the source-address ipv4 ip-address command.
l To configure the packet size, run the datasize size command.
l To configure the maximum TTL value of the packet, run the ttl number command.
l To configure the LSP EXP value, run the lsp-exp exp command.
l To configure the padding character of the packet, run the datafill fillstring command.
l To configure the interval for sending the test packets, run the interval seconds interval
command.
NOTE
The minimum interval for sending test packets is one second and the maximum interval is 60 seconds.
l To configure the percentage of the failed NQA tests, run thefail-percent percent command.
Step 7 Run:
start
The NQA test is started.
Select the start mode as required because the startcommand has several forms.
l To perform the NQA test immediately, run the start now [ end { at [ yyyy/mm/dd ]
hh:mm:ss | delay { seconds second | hh:mm:ss } | lifetime { seconds second | hh:mm:ss } } ]
command.
The test instance is started immediately.
l To perform the NQA test at the specified time, run the start at [ yyyy/mm/dd ] hh:mm:ss
[ end { at [ yyyy/mm/dd ] hh:mm:ss | delay { seconds second | hh:mm:ss } | lifetime
{ seconds second | hh:mm:ss } } ] command.
The test instance is started at a specified time.
l To perform the NQA test after a certain delay period, run the start delay { seconds second
| hh:mm:ss } [ end { at [ yyyy/mm/dd ] hh:mm:ss | delay { seconds second | hh:mm:ss } |
lifetime { seconds second | hh:mm:ss } } ] command.
The test instance is started after a certain delay.
----End
6.16.3 Checking the Configuration
After configuring the LSP jitter test, you can view the test result.
Prerequisite
The configurations of the LSP Test function are complete.
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 6 NQA Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
297
