– Number of wrong sequence numbers
– Timeout times of the test packets
l History statistics of each test packet
– Timestamp added when each test packet is sent
– Timestamp added when each test packet is received
– Packets status displayed on the NQA client
l Statistics of results of each test
– Number of successful tests
– Sum of the response time of all tests
– RTT square sum(high 32 bit and low 32 bit)
– Minimum RTT and maximum RTT of the packet
– Destination IP address and the type of the destination IP address
– Number of the Echo packets and the sent packets
– Time when the last packet is received
<Quidway> display nqa results
NQA entry(admin, test) :testflag is inactive ,testtype is lspping
1 . Test 1 result The test is finished
Send operation times: 3 Receive response times: 3
Completion:success RTD OverThresholds number: 0
Attempts number:1 Drop operation number:0
Disconnect operation number:0 Operation timeout number:0
System busy operation number:0 Connection fail number:0
Operation sequence errors number:0 RTT Stats errors number:0
Destination ip address:100.1.1.200
Min/Max/Average Completion Time: 4/5/4
Sum/Square-Sum Completion Time: 13/57
Last Good Probe Time: 2007-11-19 19:46:28.8
Lost packet ratio: 0 %
6.16 Configuring the LSP Jitter Test
This section describes how to configure an LSP jitter test to measure jitter in the LSP during the
packet transmission.
6.16.1 Establishing the Configuration Task
Before configuring an LSP jitter test, familiarize yourself with the applicable environment,
complete the pre-configuration tasks, and obtain the required data. This can help you complete
the configuration task quickly and accurately.
Applicable Environment
The NQA LSP Jitter test is performed to check the reachability of static LSP and LDP LSP.
After receiving a packet from the source, the destination calculates the maximum, minimum,
and average jitter time of the packet transmitted from the source to the destination. This clearly
reflects the status of the MPLS network.
NOTE
LSP Jitter tests do not support load balancing.
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 6 NQA Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
295
