The delay is applied to only the following traps: traps for adding neighbors, traps for deleting
neighbors, neighbor aging traps, and traps for discarding neighbor packets
(LLDP_1.0.8802.1.1.2.0.0.1 lldpRemTablesChange).
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
lldp message-transmission interval interval
The interval for sending LLDP packets is set.
By default, the interval for sending LLDP packets is 30 seconds.
Step 3 Run:
lldp message-transmission delay delay
The delay to send LLDP packets is set.
By default, the delay to send LLDP packets is 2 seconds.
Step 4 Run:
lldp message-transmission hold-multiplier hold
The hold time multiplier of device information stored on neighbors is set.
The default value is 4.
NOTE
l You can extend the storage time of device information on the neighbors by increasing the value of
hold.
l The value of hold ranges from 2 to 10; however, when the value of (hold x interval) is greater than
65535, the hold value is invalid.
Step 5 Run:
lldp restart-delay delay
The delay to re-enable LLDP on an interface is set.
The default value is 2, in seconds.
If LLDP is disabled on an interface, the system re-enables LLDP for the interface after a delay.
Step 6 Run:
lldp trap-interval interval
The delay to send neighbor change traps to the NMS is set.
The default value is 5, in seconds.
----End
2.3.7 (Optional) Enabling the LLDP Trap Function
To send traps to the NMS when the neighbor information changes, you need to enable the LLDP
trap function on the switch.
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 2 LLDP Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
60
