Huawei Quidway S5700 Series User Manual

– Minimum RTT and maximum RTT of the packet
– Destination IP address and the type of the destination IP address
– Number of the Echo packets and the sent packets
– Time when the last packet is received
<Quidway> display nqa results
NQA entry(test, pwe3trace) :testflag is inactive ,testtype is pwe3trace
1 . Test 1 result The test is finished
Completion:success Attempts number:1
Disconnect operation number:0 Operation timeout number:0
System busy operation number:0 Connection fail number:0
Operation sequence errors number:0 RTT Stats errors number:0
Drop operation number:0
Last good path Time:2009-2-28 0:42:37.5
1 . Hop 1
Send operation times: 3 Receive response times: 3
Min/Max/Average Completion Time: 8/10/9
Sum/Square-Sum Completion Time: 28/264
RTD OverThresholds number: 0
Last Good Probe Time: 2009-2-28 0:42:37.5
Destination ip address:3.14.2.14
Lost packet ratio: 0 %
6.22 Configuring the PWE3 Trace Test to Check the Multi-
Hop PW
This section describes how to configure a PWE3 trace test to check the communications between
devices on a PW.
6.22.1 Establishing the Configuration Task
Before configuring a PWE3 trace test for a multi-hop PW, familiarize yourself with the
applicable environment, complete the pre-configuration tasks, and obtain the required data. This
can help you complete the configuration task quickly and accurately.
Applicable Environment
To trace the multi-hop PW using LDP as the signaling protocol, you can perform the PWE3
Trace test on the multi-hop PW.
Pre-configuration Tasks
Before configuring the PWE3 Trace test on a multi-hop PW, you must correctly configure the
dynamic multi-hop PW or the static multi-hop PW.
Data Preparation
To configure the PWE3 Trace test on a multi-hop PW, you need the following data.
No.
Data
1 ID of the local end of the PW
2 ID or IP address of the remote end of the PW
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 6 NQA Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
316
