Page #307 background image
Pre-configuration Tasks
Before configuring the LSP Jitter test, configure an LSP tunnel.
Data Preparation
To configure the LSP Jitter test, you need the following data.
No. Data
1 Administrator name and test name
2 For the LSP tunnel: destination IP address and mask of the LSP Ping test
3 (Optional) Parameters of the LSP Jitter test, including the response mode of the Echo
packet, packet size, TTL, LSP EXP value, padding character, timeout period of the
packet, probe times, and test interval
4 Start mode and end mode of the test
6.16.2 Configuring the LSP Jitter Test Parameters for the LDP
Tunnel
This part describes how to set parameters for an LDP LSP jitter test.
Context
Do as follows on the ingress of an LSP tunnel:
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
nqa test-instance admin-name test-name
An NQA test instance is created and the test instance view is displayed.
Step 3 Run:
test-type lspjitter
The test type is set to LSP Jitter.
Step 4 Run:
lsp-type ipv4
The tunnel type is set to be the LSP tunnel.
Step 5 Run:
destination-address ipv4 ip-address { lsp-masklen masklen | lsp-loopback loopback-
address }*
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 6 NQA Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
296
