Huawei Quidway S5700 Series User Manual

Pre-configuration Tasks
Before configuring the PWE3 Ping test on a multi-hop PW, you must correctly configure the
dynamic multi-hop PW or the static multi-hop PW.
Data Preparation
To configure the PWE3 Ping test on a multi-hop PW, you need the following data.
No. Data
1 ID of the local end of the PW
2 ID or IP address of the remote end of the PW
3 Type of the PW
4 (Optional) Response mode of the Echo packets, LSP EXP, maximum hops, number
of probes, TTL value, and timeout period of the packets
5 Type and number of the interface connected with the CE
6 Start mode and end mode of the test
6.20.2 Configuring Parameters for the PWE3 Ping Test on a Multi-
Hop PW
This part describes how to set PWE3 ping test parameters for a multi-hop PW.
Context
Do as follows on the NQA client:
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
nqa test-instance admin-name test-name
An NQA test instance is created and the test instance view is displayed.
Step 3 Run:
test-type pwe3ping
The test type is set to PWE3 Ping.
Step 4 (Optional) Run:
vc-type ldp
The method of setting up a PW is configured.
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 6 NQA Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
310

Huawei Quidway S5700 Series Specifications

General

Category	Switch
Operating Temperature	0°C to 45°C
Relative Humidity	5% to 95% (non-condensing)
Series	Quidway S5700
Forwarding Performance	Up to 96 Mpps
Ports	24 or 48 x 10/100/1000Base-T ports
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C
Fixed GE Ports	24 or 48
Uplink Ports	4 x GE SFP ports
Routing Protocols	RIP, OSPF, BGP
Management	SNMP, RMON, CLI, Web
VLAN	4094 VLANs
PoE	Optional
