Huawei Quidway S5700 Series User Manual

In an FTP upload test, you can specify the file to be uploaded or the bytes to be uploaded. If
certain bytes are specified, the FTP client then automatically generates the test files for
uploading.
Pre-configuration Tasks
Before configuring the FTP upload test, complete the following tasks:
l Configuring the FTP user name and password and the login directory
l Configuring routes between the NQA client and the FTP server
Data Preparation
To configure the FTP upload test, you need the following data.
No. Data
1 Administrator name and test name
2 IP address of the FTP server
3 FTP user name and password
4 (Optional) Source IP address of the FTP operation and VPN instance name and source
and destination port numbers of the FTP operation
5 Name or size of the uploaded file
6 Start mode and end mode of the test
6.7.2 Configuring the FTP Upload Test Parameters
This part describes how to set parameters for the FTP upload test.
Context
Do as follows on the NQA client (FTP client):
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
nqa test-instance admin-name test-name
An NQA test instance is created and the test instance view is displayed.
Step 3 Run:
test-type ftp
The test type is set to FTP.
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 6 NQA Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
266

Huawei Quidway S5700 Series Specifications

General

Category	Switch
Operating Temperature	0°C to 45°C
Relative Humidity	5% to 95% (non-condensing)
Series	Quidway S5700
Forwarding Performance	Up to 96 Mpps
Ports	24 or 48 x 10/100/1000Base-T ports
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C
Fixed GE Ports	24 or 48
Uplink Ports	4 x GE SFP ports
Routing Protocols	RIP, OSPF, BGP
Management	SNMP, RMON, CLI, Web
VLAN	4094 VLANs
PoE	Optional
