Page #271 background image
6.5.2 Configuring ICMP Test Parameters
This part describes how to set ICMP test parameters.
Context
Do as follows on the NQA client:
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
nqa test-instance admin-name test-name
An NQA test instance is created and the test instance view is displayed.
Step 3 Run:
test-type icmp
The test type is set to ICMP.
Step 4 Run:
destination-address ipv4 ip-address
The destination IP address is configured.
Step 5 (Optional) Perform the following as required to configure other ICMP test parameters ( For
detailed parameter configurations, see the chapter Configuring Universal NQA Test
Parameters ):
l To configure the VPN instance to be tested, run the vpn-instance vpn-instance-name
command.
NOTE
Only S5700EI and S5700HI support the vpn-instance command.
l To configure the source interface that sends test packets, run the source-interface interface-
type interface-number command.
l To configure the source IP address, run the source-address ipv4 ip-address command.
source-address ipv4 ip-address equals the "-a" option in the ping command.
l To configure the size (packet header excluded) of the Echo-Request packet, run the
datasize size command.
datasize size equals the "-s" option in the ping command.
l To configure the time-to-live (TTL) value, run the ttl number command.
ttl number equals the "-h" option in the ping command.
l To configure the type of service (ToS) field in the IP packet header, run the tos value
command.
tos equals the "-tos" option in the ping command.
l To configure padding characters, run the datafill fillstring command.
datafill equals the "-p" option in the ping command.
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 6 NQA Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
260
