Context
NOTE
NQA test results cannot be displayed automatically on a terminal. You must run the display nqa results
command to view test results. By the default, the command output contains the records about only the last
five tests.
Procedure
Step 1 Run the display nqa results command to view the test results on the NQA client.
----End
Example
For the LSP Jitter test, run the display nqa results command. If the test is successful, the
following is displayed.
l Statistics about errors
– Number of unroutable connections
– Number of wrong sequence numbers
– Timeout times of the test packets
l History statistics of each test packet
– Timestamp added when each test packet is sent
– Timestamp added when each test packet is received
– Packets status displayed on the NQA client
l Statistics of results of each test
– Number of successful tests
– Sum of the response time of all tests
– RTT square sum
– Minimum RTT and maximum RTT of the packet
– Destination IP address and the type of the destination IP address
– Number of the Echo packets and the sent packets
– Time when the last packet is received
<Quidway> display nqa results
NQA entry(admin, lspjitter) :testflag is inactive ,testtype is lspjitter
1 . Test 1 result The test is finished
SendProbe:60 ResponseProbe:60
Completion:success RTD OverThresholds number:0
Min/Max/Avg/Sum RTT:1/24/3/156 RTT Square Sum:928
NumOfRTT:60 Drop operation number:0
Operation sequence errors number:0 RTT Stats errors number:0
System busy operation number:0 Operation timeout number:0
Min Positive SD:1 Max Positive SD:22
Positive SD Number:12 Positive SD Sum:33
Positive SD Square Sum:495 Min Negative SD:1
Max Negative SD:22 Negative SD Number:12
Negative SD Sum:34 Negative SD Square Sum:498
Packet Loss Unknown:0 Average of Jitter SD:2
jitter out value:0.8977973 Packet Loss Ratio: 0%
TimeStamp unit: ms
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 6 NQA Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
298
