Create a service VLAN and add an upstream port to it. Add upstream port 0/19/0 to VLAN
100.
huawei(config)#vlan 100 smart
huawei(config)#vlan attrib 100 stacking
huawei(config)#port vlan 100 0/19 0
Create service flows. Set the service VLAN to 100, GEM port ID to 14, and user VLAN to
1001, and use traffic profile ftth_hsi.
huawei(config)#service-port vlan 100 gpon 0/1/0 ont 1 gemport 14 multi-service
user-vlan 1001 tag-transform translate-and-add inner-vlan 1010 inbound traffic-
table name
ftth_hsi outbound traffic-table name ftth_hsi
huawei(config)#service-port vlan 100 gpon 0/1/0 ont 2 gemport 14 multi-service
user-vlan 1001 tag-transform translate-and-add inner-vlan 1011 inbound traffic-
table name
ftth_hsi outbound traffic-table name ftth_hsi
Step 7 Configure the traffic profile for the voice service.
huawei(config)#traffic table ip name ftth_voip cir off priority 5 priority-policy
local-setting
Step 8 Configure the VLAN translation policy and service port for the voice service.
Table 19-14 Scenario plan
Scenario VLAN Plan VLAN Translation Policy
Scenario 1 Single VLAN tag
l SVLAN ID: 300
l SVLAN type: smart
l SVLAN attribute: common
l CVLAN ID: 300
ONT: The iTMS issues the
VLAN of the WAN port or
factory default setting is used.
OLT: transparently transmits
VLAN (CVLAN is the same as
the planned SVLAN).
Scenario 2 Single VLAN tag
l SVLAN ID: 300
l SVLAN type: smart
l SVLAN attribute: common
l CVLAN ID: 3001
ONT: The iTMS issues the
VLAN of the WAN port or
factory default setting is used.
OLT: performs VLAN
translation: C<->S (CVLAN is
different from the planned
SVLAN).
Scenario 1:
Configure the mapping relationship between a GEM port and a VLAN. The service flow of user
VLAN 300 is mapped to GEM port 12 in the ONT line profile.
huawei(config)#ont-lineprofile gpon profile-name ftth
huawei(config-gpon-lineprofile-1)#gem mapping 12 2 vlan 300
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Create a service VLAN and add an upstream port to it. Add upstream port 0/19/0 to VLAN 300.
huawei(config)#vlan 300 smart
huawei(config)#port vlan 300 0/19 0
