Impact on System
None
Precautions
Make sure that the crossover cable is used to directly connect the TFTP server to the MA5600T/
MA5603T/MA5608T. In other cases, a straight-through cable is used.
Procedure
Step 1 On the TFTP server, configure the IP address of its Ethernet port.
Configure the Ethernet port IP address of the TFTP server according to the IP address planning
in the specific networking, and ensure that the Ethernet port of the TFTP server and the inband
or outband Ethernet port of the MA5600T/MA5603T/MA5608T can ping each other.
For example, if the Ethernet port of the TFTP server is directly connected to the MA5600T/
MA5603T/MA5608T, the IP address of this Ethernet port and the IP address of the inband or
outband Ethernet port of the MA5600T/MA5603T/MA5608T must be in the same subnet.
Step 2 On the TFTP server, run the TFTP application and set related parameters.
1. After the TFTP application is run on the TFTP server, an interface as shown in Figure
1-85 is displayed. In the Server interfaces drop-down list, select the IP address that is set
in step 1.
Figure 1-85 TFTP main interface
2. In the interface as shown in Figure 1-85, click Settings.
3. In the dialog box that is displayed, click Browse to select the path for saving the file, as
shown in Figure 1-86.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
200
