Item Data
Software parameters of the MG
interface
According to the Background
Information in (Optional) Configuring
the Software Parameters of an MG
Interface and confirmed with the
service provider, the default settings
can meet the service requirements.
Therefore, the software parameters are
not configured here.
Ringing mode of the MG
interface
Confirmed with the service provider,
the value of the ringing parameter
(corresponding to the users) defined on
the MGC is 0 (value of mgcpara), and
the users have no special requirements
for the ringing mode. Therefore, the
normal ringing with the break-make
ratio of 1:4 is adopted.
Terminal ID (TID) format of the
MG interface
To differentiate users according to the
TID, the service provider requires that
the terminal prefix uses the community
name huawei and the TID is
automatically generated by the system
according to the slot ID/subrack ID/
port ID of the user.
Run the display tid-template
command to query the default TID
template. It is found that default TID
template 6 can meet the requirements.
VoIP user data
(The data
configuration
must be the
same as the data
configuration
on the MGC.)
Slot of the voice service board User access is implemented by the
ASPB board in slot 0/3.
User data Phone number MGCP does not support emergency
standalone, and therefore the phone
number does not need to be configured
when the user is added.
The MGC assigns phone numbers
83110000-83110031 to phones 0-31
respectively.
TID The terminal layering is supported, and
therefore the manual allocation of TIDs
is not required.
User priority The users are common users, and the
user priority uses default cat3.
User type The users are common users, and the
users are of the default DEL type.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
311
