Huawei SmartAX MA5608T User Manual

Item Data
PW parameters PW ID: 10
Peer IP address: 6.6.6.6
PW type: ETH tagged
Control word: enabled
Out label: 8500
In label: 8600
Tunnel Tunnel ID: 10; tunnel interface ID: 10
Encapsulation protocol of the tunnel interface at the data link
layer: MPLS TE
Tunnel signaling protocol: RSVP-TE
ETH service port Port: 0/4/0
Emulation SVLAN: 3001
CVLAN: 20
OSPF OSPF process ID: 100; OSPF area ID: 1
Enable MPLS TE for the OSPF area
PWE3 gateway LSR ID: 6.6.6.6
Procedure
Step 1 Configure a VLAN and add an upstream port to the VLAN.
Create upstream VLAN 200 and add upstream port 0/19/0 to VLAN 200.
huawei(config)#vlan 200 standard
huawei(config)#port vlan 200 0/19 0
Step 2 Enable MPLS.
1. Configure the IP address of the loopback interface.
Configure the IP address of loopback interface 0 to 5.5.5.5/32.
huawei(config)#interface loopback 0
huawei(config-if-loopback0)#ip address 5.5.5.5 32
huawei(config-if-loopback0)#quit
2. Configure the LSR ID of the MPLS and enable global MPLS TE and Layer 2 VPN.
huawei(config)#mpls lsr-id 5.5.5.5
huawei(config)#mpls
huawei(config-mpls)#mpls te
huawei(config-mpls)#mpls rsvp-te
huawei(config-mpls)#quit
huawei(config)#mpls l2vpn
3. Enable the VLAN interface MPLS TE function and configure the IP address of the VLAN
interface.
huawei(config)#mpls vlan 200
huawei(config)#interface vlanif 200
huawei(config-if-vlanif200)#ip address 192.168.1.10 24
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
4 Configuration Example of the Private Line Service
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
416

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
