NOTE
l The parameters of the SIP-based voice user must be consistent with the
corresponding configuration on the softswitch.
l If Associated POTS Port is 1, port TEL1 on the ONT is bound. If Associated POTS
Port is 2, port TEL2 on the ONT is bound.
d. Click Apply.
4. Check the registration status of the voice user.
Choose Status > VoIP Information. In the right pane, User Status is Up.
l Configure the ONT on the U2000.
NOTE
The window for configuring ONT value-added service (VAS) profiles varies with ONT versions, but the
parameter configuration is the same. For details, see relevant ONT manuals.
1. Configure a general VAS profile for the ONT.
a. From the main menu, choose Configuration > Access Profile Management. In
the navigation tree of the tab page that is displayed, choose PON Profile > ONT
VAS Profile.
b. On the General ONT VAS Profile tab page, right-click, and choose Add from
the shortcut menu.
c. In the dialog box that is displayed, set Name to ONT-VoIP.
d. Configure the parameters of a voice WAN port.
a. In the navigation tree, choose General Para > WAN Device > WAN
Device 1 > WAN Connection. Select WAN Connection, right-click, and
choose Add IP Connection from the shortcut menu.
b. Select WAN IP Interface 1 and enter (or select) a proper value.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
688
