ENGINE REASSEMBLY
Tightening torques
1 M8x1,25 15 Nm- 1,5 Kgm- 10.8 ft/lb
2 M10x1,5 (+MOLIKOTE HSC) 37 Nm+90°- 3.8 Nm+90°- 27.5 ft/lb+90°
3 M6x1 12 Nm- 1,2 Kgm- 8.7 ft/lb
4 M14x1,5 (+LOCTITE 243) 25 Nm- 2,55 Kgm- 18.4 ft/lb
5 M6x1 8 Nm- 0,8 Kgm- 5.8 ft/lb
6 M10x1 15 Nm- 1,5 Kgm- 10.8 ft/lb
9 M6x1 (+LOCTITE 243) 8 Nm- 0,8 Kgm- 5.8 ft/lb
10 M8x1,25 10÷12 Nm- 1÷1,23 Kgm- 7.2÷8.9 ft/lb
15 M4x0,7 (+LOCTITE 272) 3 Nm- 0,3 Kgm- 2.2 ft/lb
18 M10x1 12 Nm- 1,23 Kgm- 8.9 ft/lb
25 M5x0,8 (+LOCTITE 243) 4,9 Nm- 0,5 Kgm- 3.6 ft/lb
26 M6x1(+LOCTITE 542) 8 Nm- 0,8 Kgm- 5.8 ft/lb
27 M14x1,5 (+LOCTITE 542) 25 Nm- 0,25 Kgm- 18.4 ft/lb
29 M10x1,25 (TE-SMR) 5 Nm- 0,5 Kgm- 3.6 ft/lb
29 M10x1,25 (TC-TXC) 8 Nm- 0,8 Kgm- 5.8 ft/lb
43 M5x0,8 (+LOCTITE 243) Excluded USA model 5 Nm- 0,5 Kgm- 3.6 ft/lb
STANDARD
M5x0,8 6 Nm- 0,6 Kgm- 4.3
ft/lb
M6x1 8 Nm-0,8 Kgm- 5.8 ft/lb
M8x1,25 21 Nm- 2,1 Kgm- 15.5 ft/lb
LUBRICATING POINTS-NOTES LUBRICANT-INSTRUCTIONS FOR ASSEMBLY
F Fit using “AREXONS RHODORSEAL 5552” seal
G Grease WATER RESISTANT
O Engine oil
O/G Engine oil or grease WATER RESISTANT
