H.15Part. N. 8000 H1344 (10-2009)
ENGINE REASSEMBLY
A = 0,4 ÷ 0,5 mm
(0,0157÷0,0197 in.)
B = 0,5 mm (0,02 in.)
Aligned with half-ywheel
Check the connecting rod side oat into the ywheels. It must be 0,4÷0,5 mm
(0.0157÷0.0197 in).
Check the alignment of the crankshaft between centers.
Runout may not exceed 0.02 mm (0.0008 in) at the bearing positions.
Make an initial alignment of the ywheel using a copper hammer.
