H.34 Part. N. 8000 H1344 (10-2009)
ENGINE REASSEMBLY
Tighten the two L.h. external screws (8 Nm-0,8 Kgm- 5.8 ft/lb) and the lower
nuts (15 Nm-1,5 Kgm- 10.8 ft/lb). Reassemble the lubrication hose on the
transmission cover (15 Nm-1,5 Kgm-10.8 ft/lb). If the intake manifold (A) of the
cylinder head has been dismantled, tighten the two screws to 3 Nm-0,3 Kgm-2.2
ft/lb+LOCTITE 272.
Reassemble the coolant drain screw on cylinder, R.H. side (8 Nm-0,8 Kgm-5.8
ft/lb).
