H.37Part. N. 8000 H1344 (10-2009)
ENGINE REASSEMBLY
Assembly of valve lifter
Mount the valve lifter in the head and, turning it in lift position, insert the retain-
ing pin.
Reassemble the lubrication tube.
Lubricate the cammes abundantly with motor oil.
Reassemble the four U-bolts for xing the camshaft and tight the screws to 12
Nm-1,2 Kgm-8.7 ft/lb.
