I.30
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
If the outer and inner tubes are not disassembled, turn the stem upside-down
for at least 20 minutes to ensure that the oil is fully eliminated.
Remove the dust scraper gasket using a slotted screwdriver.
Remove the lock ring using a slotted screwdriver.
Remove the inner tube from the outer tube.
N.B.: to make this operation easier, push the tubes back and forth several times
